Specifications:

• CVP Series Class A/B 2 ohms Stable 4-Channel Amplifier
• RMS Power Rating:
• 4 ohms: 55 watts x 4 channel
• 2 ohms: 75 watts x 4 channel
• Bridged: 160 watts x 2 channel @ 4 ohms
• Total power output: 300 watts
• LED Power/Protect Light
• Speaker-level (high-level) inputs
• 1 pair of pre-amp outputs
• Signal sensing remote turn-on
• 3-way protection circuitry (thermal, overload, and speaker short protection)
• Input sensitivity:
• Low level: 200mV - 6 volts
• High level: 200mV - 6 volts
• Total Harmonic Distortion (THD): <1%
• Signal to Noise Ratio: >105 dB
• Variable high-pass filter: 40 - 400 Hz
• Variable low-pass filter: 40 - 400 Hz
• Variable Bass Boost: 0 - 12 dB
• Fuse Rating: 25A
• 8 AWG gauge amplifier wiring kit is recommended for installation
• Dimensions: 11.03" L x 9.38" W x 2.25" H

Amplifier Specifications:

• Amplifier Series: CVP
• Marine Certified: No
• Amplifier Class: D
• Number of Channels: 4
• Total Peak Power Output: 1200 watts
• Total RMS Power Output: 600 watts
• Minimum Impedance Unbridged: 2 ohms
• Speaker Level Inputs: No
• Preamp Outputs: No
• Built-in Crossover: Low-Pass (LP), High-Pass (HP), Subsonic
• High-Pass Crossover Frequency: 40 - 400 Hz
• Low-Pass Crossover Frequency: 40 - 400 Hz
• Bass Boost: 0 - 12 dB
• Strappable: No
• CEA-2006 Compliant: No
• Amp Bluetooth Connectivity: No
• Hi-Res Certified: No
