The BLADE BP Series are designed with our “Live, Loud and Play Hard” motto. All amplifiers have built-in OEM line converters with RCA inputs that can take a high level speaker signal at up to 9 Volts directly in. By sensing the DC off set of a factory radio it can activate the ATO (Auto Turn On) feature and convert the 12V turn on into a 12V switched out. Blade “BP” are Class AB designed with a minimum per channel impedance operation of 2 Ohm with the exception of the BP2000.1, BP1200.1 which are Class “D” and can play down to 1 Ohm minimum. The monster BP4000 & BP6000 are full range Digital and 2 OHM stable. All Blade “BP” amps use Mil Spec PCBs, SMD parts, 5 way protection, full MOSFET high grade switching devices and all comply with the “World Wide Standards”, “ROHS”, “E-Mark” and are CTA2006 Compliant. This ensures that no competition can stand up to the BLADE BP when it comes to features, performance and value.
Manuals & Downloads
FEATURES
- Built-In OEM Line Converter
- 2 Ohm Stable Design
- Low Pass Frequency / OFF Crossovers
- Up to 9 Volt Input via RCA or High Level Speaker Leads
- Bass Boost 0dB ~ 12dB @ 45Hz
- Built-in Noise Reduction Circuitry
- Full MOSFET with High Grade Switching Devices
- Built-In, DC Offset, Auto Sensing Turn On Function (Hi-Level Inputs)
- 12V Remote Output for External Devices (Hi-Level Inputs)
- Variable Low Pass Crossover Frequencies from 50Hz ~ 750Hz
- Ground Loop Isolator
- Next Generation Advanced 5 Way Protection Circuitry
- High Output Power Supply & Dual Output Voltage
- Mil Spec PCB with SMD parts
- World Wide Standards Compliant (RoHS, E-Mark, CTA-2006, CE)
SPECIFICATIONS
| Peak Output Power @ 14.4V | 250W x 4 |
| 1 Ohm RMS | N/A |
| 2 Ohm RMS | 160W x 4 |
| 4 Ohm RMS | 80W x 4 |
| 4 Ohm Bridged | 320W x 2 |
| Input Level | 0.2~9.0v |
| Freq. Response | 10Hz~35KHz |
| THD at 4 Ohm Load 30% Rated Power | <0.05% |
| S/N Ratio | >90dB |
| BassBoost | 0~12dB (45Hz) |
| Minimum Load | 2 Ohm Stereo |
| Gain Remote | n/a |
| Dimension | 2"H x 7.1"W x 12.6"L |
