Celestion NTR10 2520D 8 Ohm 10-Inch 250W Neodymium Professional Audio Woofer Speaker - Perfect for Live Sound, DJ Equipment, and Studio Monitors (Model T5638)
$127.03
$230.97
Safe 45%
Celestion NTR10 2520D 8 Ohm 10-Inch 250W Neodymium Professional Audio Woofer Speaker - Perfect for Live Sound, DJ Equipment, and Studio Monitors (Model T5638)
$127.03
$230.97
45% Off
Delivery & Return: Free shipping on all orders over $50
Estimated Delivery: 10-15 days international
6 people viewing this product right now!
SKU: 73906183
Guranteed safe checkout
Description
Features Include
- 10" neodymium mid/bass unit offers 250Wrms (AES standard) power handling and 96dB sensitivity
- 2.5" high temperature Inside/Outside voice coil efficiently dissipates heat, preventing sensitivity loss through thermal compression
- "M-roll" surround provides progressive excursion control, yielding a smooth response even at extremes of frequency range
- Extremely lightweight design combined with a highly efficient magnet assembly results in exceptional power-to-weight ratio
- Intelligent heat management in both chassis and magnet assembly design further minimizes distortion
General Specifications
Nominal diameter: 254mm/10in
Power rating: 250Wrms
Continuous power rating: 500W
Nominal impedance: 8Ω
Sensitivity: 96dB
Frequency range: 55-3,500Hz
Voice coil diameter: 64mm/2.5in
Chassis type: Cast aluminium
Magnet type: Neodymium
Coil material: Copper clad aluminium
Former material: Glass fibre
Cone material: Kevlar loaded paper
Surround material: Cloth sealed
Suspension: Single
Xmax: 4mm/016in
Gap depth: 8mm/0.32in
Voice coil winding width: 16mm/0.63in
Small Signal Parameters4
D: 0.21m/8.27in
Fs: 57.2Hz
Mms: 37.93g/1.34oz
Qms: 2.824
Qes: 0.322
Mmd: 36.57g/1.29oz
Qts: 0.289
Re: 5.92Ω
Vas: 34.69lt/1.23ft3
BI: 15.83Tm
Cms: 0.2mm/N
Rms: 4.82kg/s
Le (at 1kHz): 0.49mH
Mounting Information
Overall diameter: 260mm/10.24in
Overall depth: 113mm/4.45in
Cut-out diameter: 232mm/9.13in
Mounting slot dimensions: 7.5mm x 6.5mm/0.3in x 0.26in
Number of mounting slots; 4
Mounting slot PCD range: 244-247mm/9.6-9.7in
Unit weight: 2.2kg/4.89lb
